Prodajem Hertz HP1D monoblok, originalna ambalaža i bass remote kontroler. Fali plastični poklopac na kontrolama. Ima displej s prikazom temperature i napona. Cijena 1900kn

Specifikacije:

Output Power (RMS):
700W x 1 @4-ohm
1400W x 1 @2-ohm
2300W x 1 @1-ohm
HP Link mode RMS Power:
2300W x 1 (4-ohm - HP LINK)
4000W x 1 (2-ohm - HP LINK)
Low Pass Filter: 50 - 350Hz @24dB/Oct (L+R)
Subsonic: By-pass / 10 - 50Hz @24dB/Oct
Output Phase Selector: 0/180 Degrees
HP LINK mode: Master/Slave
Bass Boost: 0-18dB @50Hz
Output Filter: Bypass / 59-350Hz @12dB/Oct
T.H.D. (100Hz @4-ohm): 0.05%
Bandwidth (-3 dB): 4 - 350Hz
S/N Ratio (A weighted @1V): 87dBA
Damping Factor (100Hz @4-ohm): 100
Pre-In sensitivity: 0.4-5Volts
Pre-In impedance: 15 ohms
Speaker-In sensitivity: 1.4-24Volts
Speaker-in impedance@ 5kOhms
Load impedance: 4-1Ohms
Power supply voltage: 11 - 16Volts
Idling current: 2.6A
Idling current when off: 0.05mA
Consumption @1, 14.4VDC: 120A
Remote In: 7-16 VDC - 1mA
Remote Out: 12 VDC - 50mA
Automatic Turn On/Off with speaker in
Fuse: 300A (AFS - external)
HP RVC (Digital remote Volume Control): Level: -36, +6dB
Dimensions (mm): 240 x 548 x 55
